Tube OD

L

I

HEX

JL1T

1/16

0.70

0.55

3/8

JL2T

1/8

0.88

0.62

3/8

JL3T

3/16

1.00

0.74

1/2

JL4T

1/4

1.06

0.77

1/2

JL5T

5/16

1.13

0.84

9/16

JL6T

3/8

1.20

0.91

5/8

JL8T

1/2

1.42

1.02

13/16

JL10T

5/8

1.50

1.10

15/16

JL12T

3/4

1.57

1.17

1-1/16

JL14T

7/8

1.76

1.36

1-3/8

JL16T

1

1.93

1.45

1-3/8

JL20T

1-1/4

2.61

1.75

1-5/8

JL24T

1-1/2

3.06

2.00

1-7/8

JL32T

2

4.22

2.75

2-13/16
